Lab Automatic 300mm Tape Casting Coater Film Coating Machine

Model Number:AOAO-TM300
Dimension(L*W*H):Stroke Length:100-800 mm
Net Weight:50 kg (135 lbs)
Compliance:CE Certified
Warranty:One Year limited warranty with lifetime support
Payment:T/T, Western Union, PayPal, Credit Card, Cash, Alipay, L/C etc.
Delivery Time:5 days

Lab Automatic 300mm Tape Casting Coater Film Coating Machine

The automatic coating and drying machine is widely used in research, including ceramic films, crystal films, battery material films, and specialized nano-films. It is designed to support scientific advancements in film formation under high-temperature conditions.

Key Features

· Bottom heating drying system for efficient and uniform drying.

· Adjustable coating speed ranging from 0 to 100mm/sec.

· Digital temperature control drying system for precise heating management.

· Adjustable stroke range (10-250mm) via a travel switch, with a vacuum aluminum plate for easy and quick placement or removal of substrates.

· Equipped with an adjustable film applicator for enhanced coating precision.

Technical Specifications

Parameter	Specification
Coating Speed	0-100 mm/sec (adjustable)
Maximum Stroke	250mm
Vacuum Plate	Equipped with a vacuum aluminum plate
Vacuum Plate Size	365mm × 200mm × 30mm (L × W × H)
Blade Adjustable Range	0.01 - 3.5mm
Power Supply	220V / 50Hz
Machine Weight	50kg
Machine Dimensions	500mm × 310mm × 260mm (L × W × H)
