Steel Split Test Cell For Lithium Air Battery Research

Steel Split Test Cell For Lithium Air Battery Research

Model Number:EQ-STC-LI-AIR
Net Weight:5 Kg (65 lbs)
Compliance:CE Certified
Warranty:1 year
Payment:T/T, Western Union, PayPal, Credit Card, Cash, Alipay, L/C etc.
MOQ:1

Steel Split Test Cell For Lithium Air Battery Research

1. The EQ-STC-LI-AIR is Split Test Cell for Lithium Air Battery Research.

2. You can control air flow pressure and test various anode and cathode material at easy.

SPECIFICATIONS:

Structure	1. Stainless Steel Structure with internal Silver-Clad surface treatment ensures high electrical conductivity and good corrosion protection 2. Two electrodes design 3. Electrolyte corrosive-proof PTFE Guide Sleeve and Sealing O-rings 4. Compact design fits in any benchtop glove boxes 5. Grooved area on lower split to fixed position of the anode electrode
Cell Thickness	1~3mm (cathode+separator+anode)
Bottom Recesss Area	16mm Dia. (The recess area can accommodate the electrodes with size upto 16mm dia.)
Max. Working Temperature	200°C
Valves & Fittings	Two Stainless Steel needle valves and 1/16" tube connector is installed on both gas inlet and outlet
Warranty	One Year limited manufacture warranty with lifetime support
Dimensions	Φ80×62mm
