Electrode Hydraulic Laboratory Press Machine

Gauge Pressure Value to Force Conversion

· Notes:

· Displayed Pressure Value to Actual Applied Force Conversion: 1 MPa = 0.6 Ton

· The actual force applied on the Hydraulic Cylinder (Ton) equal to the force applied on your working piece

· For calculating the actual pressure (MPa) applied on your working piece, please follow the equations in below:

          P = T/(πr^2) x g x 10

· P: Pressure (MPa) applied on your working piece

· T: Force (Ton) applied on the Hydraulic Cylinder

· g: Standard gravity. g ≈ 9.8 m/s2

· π: ~3.14

· r: Radius (cm) of the working piece

· *1 Metric Ton = 1000 kg; 1 MPa ≈ 10 kgf/cm2

Pump

Build-in Hydraulic Pump

Warranty

Two year limited manufacturer warranty with lifetime support.

Bottom Hydraulic Cylinder Travel Distance

Standard 30mm, opitional other distance

Dimensions of Machine

230mm X 200mm X 330mm

Compliance

CE Certified

Net Weight

30 kg

Press Dies

Pressing dies with various diameters are available upon request
