Model Number:AOAO-TCH-GY150A
Dimension(L*W*H):100mm-400mm can be customized
Net Weight:50-140kg
Compliance:CE Certified
Warranty:One-year warranty and lifetime maintenance
Payment:T/T, Western Union, PayPal, Credit Card, Cash, Alipay, L/C etc.
Delivery Time:5 days

8" Width Heat Calendering Machine With Variable Speed Up To 150C For Coin Cell Research

Application

The rolling machine is designed for laboratory-scale rolling press of small quantities of precious metals (gold, silver), and non-ferrous metals (copper, aluminum) under controlled heating conditions. It allows adjustable rolling thickness and simple operation, making it particularly suitable for thinning and increasing the density of in clean energy applications.

Key Features

·Heated rolling system, with adjustable temperature control displayed digitally.

·Selectable heating or non-heating operation for flexible processing.

·High-hardness rollers, surface chrome-plated for rust prevention, achieving HRC62 hardness.

·Inclined wedge gap adjustment system, ensuring self-locking stability and high adjustment accuracy.

·High rolling precision, with roller cylindricity ≤ ±2μm.

·Vertical design, facilitating easy feeding of sheet and strip materials.

·Gear-driven system, enabling precise rolling pressure.

·Adjustable pressing thickness and speed, with a sleek and modern design.

·Electric rolling system, supporting automated operation with forward and reverse rolling.

·Compact size, ensuring ease of use and operational flexibility.

Specifications

Model	JS100L	JS150L	JS200L	JS250L	JS300L	JS330L	GY200W
Roller Dimensions	96mm(Dia.) x100mm(W)	96mm(Dia.) x150mm(W)	96mm(Dia.) x200mm(W)	96mm(Dia.) x250mm(W)	96mm(Dia.) x300mm(W)	96mm(Dia.) x330mm(W)	200mm(Dia.) x 200mm(W)
Working Voltage	110V - 240V AC, 50/60Hz, automatic switch for worldwide use
Structure	Heavy duty steel frame, gears, and handle Dual micrometer for accurate thickness adjustment in the range 0 - 2 mm Maximum
Roller	1. Roller diameter tolerance: 0.004mm 2. Material: Made from hardened tool steel (RC > 62) with Cr electroplated coating 3. Rolling Speed: 0-40mm/s adjustable
Roller Surface Hardness	62 HRC Never roll materials with hardness > 50HRC
Compliance	CE Certificate
Warranty	Two Years limited warranty with lifetime support
Warnings	1. Never roll materials with hardness > 50HRC 2. In order to prolong the lifespan of the roller bearings, regular lubrication is recommended. 3. Multi-step thickness calibration: When calibrating the thickness, make increment/decrement of 0.1mm or 20% of sheet thickness each time. 4. Must clean roller surface for each rolling and use acetone to clean and lubricate when not in use to avoid corrosion 5. This rolling machine can be used under Ar gas.
