Lab Electric Coin Cell Crimper Crimping Machine For CR20XX Coin Cells

Model Number:AOAO-160S
Dimension(L*W*H):250 x 150 x 450mm
Net Weight:25 kg (55 lbs)
Warranty:Two years limited warranty with lifetime technical support
Payment:T/T, Western Union, PayPal, Credit Card, Cash, Alipay, L/C etc.
Delivery Time:5 days

Lab Electric Coin Cell Crimper Crimping Machine For CR20XX Coin Cells

Features

It's used for various of button cell electric crimping .
Standard configuration can be used for disassembling CR20 series of coin cell. The machine has the advantages like small dimensions, easy operation, stable crimping , etc. Equipped with different moulds

can also be used for other works like powder pressing ,button cell disassembing etc .

1.Electric operation with touch screen .
2.High precision moudel design to ensure stabe sealing
3.Simple to change crimping die .

4.Small size can be put into glovebox through φ360 antechamber.

We also supply quality for you! Your satisfaction is our nice purpose!

Technical Parameter

Power	110 - 240V AC 50/60Hz for universal use 24V DC motor with reducing gear, 20W
Die Set & Compatibility	Assembling dies for crimping CR2032, CR2025, & CR2016 coin cells (Optional CR2325, CR2450 die sets are available upon request).
Pressure	1. The pressure applied to seal the cell case is pre-set to a constant pressure at about 800 kg before shipping. 2. Pressure adjustment knob at the top can be used to adjust the pressure applied to the negative cap of the cell to prevent case deformation.
Structure	Heavy Duty Steel Platform
Protection Shield	Protection shield / enclosure (plexiglass) with safety interlock is installed
Product Dimensions	250mm(L) x 150mm(W) x 450mm(H)
Compliance	CE
Warranty	Two years limited warranty with lifetime support
Maintenance Notes & Warnings	1. Electrolytes are highly corrosive materials.The die set must be cleaned with alcohol after each use to avoid corrosion 2. The PTFE die (found at the top die) ejects the cell casing after crimping via spring loaded pressure. Do NOT over tighten the pressure adjustment knob to avoid damaging this PTFE die. 3.To set the proper pressure on the die, loosen the knob all the way until the spring compression is no longer stressed. Then start tightening the knob and stop turning it once the spring compression is felt. 4.This will prevent the PTFE die from becoming deformed by being subjected to excessive pressure.
Net Weight	32 kg
Shipping Weight	46 kg
