Heat Electrode Film Coater With Dryer Cover And 100-250mm Doctor Blade

Model Number:AOAO-JK-TMJ-200
Dimension(L*W*H):100-250 mm width
Net Weight:45-90kg
Compliance:CE Certified
Warranty:One Year limited warranty with lifetime support
Payment:T/T, Western Union, PayPal, Credit Card, Cash, Alipay, L/C etc.
Delivery Time:5 days

Heat Electrode Film Coater With Dryer Cover And 100-250mm Doctor Blade

AOAO-JK-TMJ-200 is a with a heating cover designed to produce films with consistent thickness. It has an unique driving system to produce smooth coating on all types of materials. The flat vacuum chuck is built in to hold substrate sheet in place, which is particularly useful when making thin coatings. One 100 mm width adjustable micrometer applicator (doctor-blade) and an oilless vacuum pump are included for immediate use. Heating cover with digital temperature controller can dry films after coating up to 200°C with a temperature accuracy of +/-1°C. This equipment can be used for researches on ceramic tape castings and Li-Ion battery electrode coating. we are dedicated to providing quality for you.

Main technical parameters	Automatic coating dry machine
Source voltage	AC 220V/110V, 50HZ
Power	650W
Coating speed	0-120mm/s, Step-less transmission
Max coating size	100250mm(could reach 250300mm for similar type)
Vacuum board material	Aluminum alloy
Vacuum board size(LWH)	36520030mm
Slicker adjustable range	0-6mm
Slicker width	0-100mm(max. Reach to 250mm)
Heating dry system	RT-200°C, Digital temperature controller
Temperature control accuracy	±1°C
Dimension(LWH)	550330320mm
Weight	About 60kg
