Automatic Spot Welding 18650 Cells Single Side Spot Welding Machine

Automatic Spot Welding 18650 Cells Single Side Spot Welding Machine

This machine is used for18650,26650,32650 cylinder battery pack automatic spot welding.

Brand:AOAO NEW ENERGY
item no.:AOAO-DH10000
order(moq):1set
Payment:L/C,T/T,Western Union, Paypal
product origin:China
shipping port:XIAMEN
Lead Time:7days

Automatic Spot Welding 18650 Cells Single Side Spot Welding Machine

This machine is used for18650,26650,32650 cylinder battery pack automatic spot welding.

Features :

1.Support break point start, support automatic start and manual start mode conversion.

2.It has a false spot welding and out of spot welding alarm function.

3.Programming is simple, and it supports any point programming and array programming. 999 groups can be saved programming files.

4.Welding needle replacement forecast reminder.

5.Own welding current monitoring system, real-time monitoring of welding current.

Model	AOAO-DH-10000
X-axis travel	380mm
Y-axis travel	540mm
Spot welding speed	0.5s / point;1600pcs / h
Maximum speed of motor drive	1000mm/s
The maximum number of batteries loaded	300pcs (standard 18650 lithium battery)
Number of groups for storing files	99 groups
Operating system	Embedded system + man-machine screen
Transmission	Stepper + imported precision linear guide (optional servo + screw)
Power supply	Single-phase 220V ± 10% / 50Hz ± 10%
Power	<500w
Air supply	0.3 ~ 0.4Mpa
Weight	200KG
Dimensions	About 1000mm1000mm1800mm
