30L Lifting Device For Planetary Vacuum Mixer For Lithium Battery Lab & Production Slurry Preparation

Model Number:AOAO-QTSJ-30L
Compliance:CE Certified
Warranty:One years limited warranty with lifetime technical support
Payment:T/T, Western Union, PayPal, Credit Card, Cash, Alipay, L/C etc.
Delivery Time:60 days

30L Lifting Device For Planetary Vacuum Mixer For Lithium Battery Lab & Production Slurry Preparation

Ⅰ. Equipment Features:

Application Scope

Lifting device for transfer tank lids.

Ⅱ. Main Technical Parameters:

Control System

Air Supply Pressure: 0.5–0.6 MPa (utilizing dry compressed air)

Air Consumption: 15 liters per minute

Lift Control Panel: Manual directional valve (equipped with a self-locking feature)

Control Mode: Manual operation

Lifting Capacity: Maximum 200 kg

Equipment Weight: Approximately 350 kg

Dimensions: 1260 mm (L) × 792 mm (W) × 1497 mm (H) (Raised height: 2097 mm)

Exterior Color: Ivory white

Floor Load Requirement: 400 kg per square meter

Ⅲ. Key Component Brands:

No.	Name	Specification	Material	Qty	Remarks
1	Cylinder	ΦD×ΦN	Aluminum	1	Airtac
2	Pneumatic Valve	—	—	1	Airtac

Ⅳ. Supporting Conditions:

No.	Item	Standard Requirement
1	Workshop Height	> 2.0 m; Ensure clearance for lifting and maintenance; Clean and level floor
2	Door Size	Height > 1.5 m; Width > 1.0 m; For equipment transport
3	Heating	In cold northern winters, indoor temperature must be > 20 °C to prevent grease from gelling in the cylinder and ensure smooth lifting and lubrication system operation
4	Installation Space	Refer to the overall layout plan
5	Others	No corrosive or explosive gases or liquids
