1200℃ Intelligent Chamber Atmosphere Furnace

1200℃ Intelligent Chamber Atmosphere furnace

SPECIFICATIONS

The vacuum system of the atmosphere furnace adopts special design technology, which is safe and convenient to operate, with good vacuum degree, and the ultimate vacuum degree can reach 0.1MPA. It has good sealing performance and long vacuum holding time. The atmosphere furnace can be filled with various atmosphere gases such as oxygen, nitrogen, and argon, with the limit value of atmosphere pressure at 0.1MPA. It adopts unique water-cooled sealing technology at the furnace port, ensuring long-term safety and convenient operation.

Product Features:

1. Uses resistance wire as heating elements and employs a double-layer shell structure.

2. The controller is mounted on the side of the furnace door, capable of meeting various rapid sintering requirements.

3. The microcomputer PID controller offers simplicity in operation, precision, reliability, and safety in temperature control.

4. The furnace chamber utilizes alumina polycrystalline fiber material to ensure durability and longevity.

5. Excellent door sealing minimizes heat loss and enhances temperature uniformity within the furnace chamber.

6. A forced-air cooling system is equipped between the double-layer furnace shells, enabling rapid heating and cooling.

Multi-segment Programmable Controller:

1. Microcomputer programming controls temperature, time, heating rates, and other parameters, enabling rapid sintering tests to be conducted efficiently.

2. Programmable controller with a 31-segment temperature control system, incorporating phase-shifting trigger and silicon-controlled rectification.

3. Utilizes microprocessor P.I.D. control mode with multi-segment programmable control, truly realizing automatic control and operation.

Safety Features:

1. Equipped with an over-temperature protector, power-off function when the door is opened, a cooling fan on the cabinet surface, and an alarm system for abnormal conditions in the resistance furnace (including heater failure, temperature sensor malfunction, memory content abnormality, and over-temperature issues), providing audible and visual alerts to ensure safe and accident-free operation.

2. Incorporates various safety protection measures such as over-current, over-voltage, and over-heating to guarantee the safe use of the electric furnace.

3. Ceramic fiber board is chosen as the thermal insulation material, offering excellent insulation properties and low surface temperature on the cabinet shell.

Technical Parameters:

Optional accessories

1. Paperless recorder

2. Air supply system

3. Flow meter

4. Rotary vane vacuum pump
