Desktop Hot Pressing Machine

Desktop Hot Pressing Machine

SPECIFICATIONS

1.Equipment description
The machine has simple structure and easy operation.During operation, first turn on the power of the equipment and let the equipment heat up by itself. After reaching the required temperature, place the material to be pressed flat on the lower pressing plate, set the required pressing time and required cylinder pressure, and use the foot pedal start the operation, the air cylinder moves, the upper pressure plate descends and presses with the lower pressure plate. After the pressing time is up, the upper pressure plate automatically rises, the two pressure plates are separated, and the pressed material is taken out.

2.Description (Specification model)

Dimensions of the pressure plate200mm*200mm

 Plate material steel

Working pressure 1 ton

3. Basic equipment
1 ton cylinder
Upper and lower aluminum heating plates
Upper and lower working plate thickness 25MM
Panasonic temperature controller
Omron time relay 0-999.9 seconds adjustable
FOTEK Solid State Relay
Safety light curtain protection
Configuration power supply: AC220V/50HZ Power: 2.0KW
Equipment weight: about 100 KG

4.Technic parameter
The maximum pressure of flat pressing is according to customer needs
Parallelism of upper and lower heating plate ≤0.03mm
Heating temperature and pressure adjustable
Adjustable pressing gap
Temperature control range: indoor temperature ~ 250 ° temperature error: ± 2 °
Equipment size: length560mm*width 350mm * height 970 mm
