Coin Cell Case Holder For CR20XX

Model Number:AOAO-holder
Compliance:CE Certified
Payment:T/T, Western Union, PayPal, Credit Card, Cash, Alipay, L/C etc.
Delivery Time:2 days
Price:US $54/bag

Coin Cell Case Holder For CR20XX

About this item

· Type:Battery Holder.Nominal Voltage:3V.

· Holder size:20mm/0.79".Body Size:22.9 x 32mm / 0.9 x 1.26"(DxH) . Distance Between Terminals : 20mm / 0.79".

· Conventional Heat Resista:200 degrees Celsius.Color:Black.

· Made of high quality PBT and manganese steel. Small size to carry easily.Long service life.

· Package included:10x Coin Cell Button Battery Holder Case.

Product Description

Specifications:
Type:Cell Battery Holder.
Material: PBT , Manganese Steel.
Batter type: CR2032 CR2025 CR2016.
Nominal Voltage:3V.
No. of Batteries:1.
Battery Terminals:PCB Pins.
Conventional Heat Resista:200 Degree Centigrade.
Holder size : 20mm/0.79".
Body Size:22.9 x 32mm / 0.9 x 1.26"(DxH) .
Distance Between Terminals:20mm / 0.79".
Color:Black.
Description:
This cell battery socket holds both two CR2032, CR2025,CR2016 batteries to achieve 3 Volts. The bottom side has 2 pins to secure onto a circuit board or wiring harness.

Package included:
10x Coin Cell Button Battery Holder Case

You may need coin cell case:

Name	Model/Size	Material
Coin cell case	CR2032	304ss/316ss/Gold-Coated/Al-Coated/ Kapton
	CR2016	304ss/316ss/ Kapton
	CR2025	304ss/316ss
	CR2450	304ss
	CR2430	304ss/316ss
	CR2325	304ss
	CR1620	304ss
	CR1632	T:3.2mm D:16mm 304ss
	CR1616	304ss
	CR1220	304ss
	CR1820	304ss
	CR0927	304ss
	CR1220	304SS
	CR1025	304SS
	CR1016	304SS
	CR3048	304SS
	CR3032	304SS
	CR2477	304ss
	CR2032 Lithium air case	304ss
Coin cell spacer	15.8*0.2mm	304ss/316ss
	15.8*0.5mm	304ss/316ss/Pure aluminum
	15.8*0.8mm	304ss/316ss
	15.8*1mm	304ss/316ss
	20.2*0.4mm	304ss
Wave Sprin (Belleville Washers)	15.4O.D10.5 I.D1.0Height*0.25 Thickness mm	304ss/316ss
Wave Sprin (Belleville Washers)	15.4O.D10.5 I.D1.0Height*0.25 Thickness mm	304ss/316ss
Coin Cell Conical Spring	15.4 mm dia * 1.1 mm height *0.25 mm thickness	304ss/316ss
Coin Cell Conical Spring	20*1.7mm	304ss

When you order more than 5000sets, Our also can put your company Logo on to case and give you the wholesale price .

The advantage of the 316: 316SS and 304SS on the chemical composition of the main difference is that 316SS contains Mo, and generally accepted, the 316 has better corrosion resistance, more resistant to corrosion under high temperature environment.
