Automatic Winding Machine For Prismatic Battery

This machine is full automatic winding machine used for prismatic pouch cell continuous roller winding.

Item No.:AOAO-AWM-P
Order(Moq):1set
Payment:L/C,T/T,Western Union, Paypal
Product Origin:China
Shipping Port:XIAMEN
Lead Time:7days

Automatic Winding Machine For Prismatic Battery

SPECIFICATIONS

1 This machine isfull automatic winding machineused forprismatic pouch cell continuous roller winding.

2 It includes cathode/anode electrode and battery separator auto volume-Dust, Iron and electrostatic remove-Auto winding-

Tape stick-Good products automatic delivery to collecting table, bad product out automatically.

3 The total winding process is full automatically.

Model		Automatic Winding Machine AOAO-AWM-P
Source voltage		AC220V/50Hz/Single phase. Customized according country request
Power		3.8KW
Warranty		One year limited warranty with lifetime support
Compressed air		0.4～0.6Mpa
Suitable battery size		According to customer’s requirement
Operating environment		Temperature : 20～35℃ Humidity : 5～55％HR
Material	Feeding mode	Material width (mm)	Material thickness (um)	Max outside diameter (mm)	Inner diameter (mm)
Electrode	Roller	100-200	100-280	Ф360	ф76.2
Separator		100-200	16-25	Ф280
Tape		20-60	20-50	Ф150
Winding accuracy		0.5mm
Winding error		0.3mm
Separator tension		0.05-0.5kg
Electrode tension		0.05-0.5kg
Output		4-7PPm
*Dimension (LWH)*		*240013002000mm*
Weight		1200kg
